197kWh Commercial Grid Scale Energy Storage Lithium Battery
This large scale commercial battery system incorporates an energy storage converter and a PV converter, and can generate electricity efficiently using PV. It can be directly connected to photovoltaic solar panels to prioritize battery charging, as well as convert the photovoltaic current output into grid-available power.
Features
-
Proven LiFePO4 chemistry with good consistency and superior charging & discharging performance
-
Modular system to flexibly match various industrial and commercial scenarios
-
Parallel connection supports the expansion of capacity up to a megawatt level
-
Efficient thermal management design to ensure safety and reliability
-
IP55 protection grade allows for outdoor installation
-
Built-in EMS supports multiple operating modes
-
Seamless switching to power supply by converter
Product Details
| Model | CBS200 |
| Power | 100KW |
| Energy | 197kWh |
| Battery | 704V280Ah (220S1P) |
| Charging and Discharging Rate | 0.5C |
| DC-side Voltage Range | 638V~770V |
| Maximum AC Output Capacity | AC400V-140A |
| Photovoltaic Input Range | 500-900VDC |
| IP Degree | IP55 |
| Communication | RS485 / CAN2.0 |
| User Interface | 7” display |
| Cooling Mode | Forced Air Cooling |
| Fire Protection | Heptafluoropropane |
| Cycle Life | ≥6000cycles (EOL 70%) |
| Altitude | 5000m |
| Dimension | 2150*1800*2350mm / 84.6*70.9*92.5in |
| Weight | 3500kg / 7716lbs |
| Ambient Temperature/Humidity | -30℃~50℃ / 0%~95% |
| Certification | UL 1973, IEC 62619, UN 38.3, UL 9540A, GB/T 36276 |
Wide Range Of Applications
