48V 100Ah LiFePO4 Battery For Golf Cart CLASSIC48100
Polinovel LiFePO4 battery for golf cart has a good performance, a longer lifespan, long-term stability, and many other advantages, giving you a wonderful user experience.
Features
-
Good-quality LiFePO4 battery cells
-
Intelligent BMS
-
Fast charging
-
Customized battery solution for easy drop-in replacement
Product Details
| ELECTRICAL SPECIFICATIONS | |
| Model | CLASSIC48100 |
| Nominal Voltage | 51.2V |
| Nominal Capacity | 105Ah |
| Energy | 5370Wh |
| Self Discharge | <3%/month |
| Maximum Modules in Series or Parallel | N/A |
| MECHANICAL SPECIFICATIONS | |
| Dimensions (L x W x H) | 770*200*275mm (30.3*7.9*10.8 in)/ 472*334*243mm (18.6*13.1*9.6 in) / Customizable |
| Weight | 45-50kg (99.2-110 lbs) |
| Terminal Type | Customizable |
| Case Material | SPCC Steel With 250℃ High-Temperature Baking Paint |
| Enclosure Protection | IP65 |
| Cell Type | Prismatic |
| Chemistry | LiFePO4 |
| CHARGE SPECIFICATIONS | |
| Recommended Charge Current | 20A |
| Charge Current (0 to -10 ºC) | ≤0.1C |
| Charge Current (-20 to -10 ºC) | ≤0.05C |
| Recommended Charge Voltage | 56.8V-58.4V |
| Charge Voltage Cut-Off | 58.4V |
| DISCHARGE SPECIFICATIONS | |
| Maximum Continuous Discharge Current | 100A / 150A |
| Peak Discharge Current | 200A(<10s) / 350A (<120s) |
| Discharge Voltage Cut-Off | 40V |
| TEMPERATURE SPECIFICATIONS | |
| Discharge Temperature | -20 to 60 ºC (-4 to 140 ºF) |
| Charge Temperature | 0 to 45 ºC (32 to 113 ºF) |
| Storage Temperature (1 month) | -20 to 60 ºC (-4 to 140 ºF) |
| Storage Temperature (3 months) | -20 to 45 ºC (-4 to 113 ºF) |
| Storage Temperature (6 months) | -20 to 25 ºC (-4 to 77 ºF) |
Wide Range Of Applications
